Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	50 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Power output:	IEC connector (F) mounting version
Fuse:	5 x 20 mm, T 1 A fuse replaceable
Lamp type:	LED lamp
LED type:	144 x SMD 5050 4in1 QCL RGBW (homogenous color mix)
Flash rate:	0 - 20 Hz
DMX channels:	6; 9; 16; 30; 58
DMX input:	3-pin XLR (M) mounting version
DMX output:	3-pin XLR (F) mounting version
Cooling:	Passive convection cooling
Control:	Stand-alone; master/slave function; sound to light via microphone; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Fixtures available for:	Light Captain
Projection:	Flicker-free
Beam angle:	120°
Beam angle (1/2 peak):	120°
Housing color:	Black
Attachment system:	2x mounting bracket
Display type:	4 digit 7-segment LED display
Material:	Metal
Dimensions:	Length: 108.5 cm Depth: 6.5 cm Height: 9.0 cm
Weight:	1.63 kg
Noise classification:	Class 0 (no noise at all)
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397708561	1,94 kg	103cm x 12cm x 11cm
8	4026397708578	16,80 kg	106,5cm x 49cm x 27cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Support

Name	Version	Language
51930351-Support-147757-Fixture-fuer-Colorchief-de.zip (249 B)	0.0000	de

All images

Name	Version	Language
51930351-Images-.zip

Video link

EUROLITE LED PIX-144 RGBW Bar

Name: EUROLITE LED PIX-144 RGBW Bar
Uploaded: 2022-01-01
Description: LED light bar with 144 wide beam SMD LEDs in RGBW and pixel control

Stock for approx. 12 wk(s)

129,00 €

Find a dealer

Stock for approx. 12 wk(s)

List price excl. 19% VAT
Prices in retail stores may vary.

No. 51930351

120°

LED light bar with 144 wide beam SMD LEDs in RGBW and pixel control

Additional frost filter provides a wide, soft and homogeneous light
144 LEDs SMD 5050 4in1 QCL RGBW (homogenous color mix)
8 segments controlled separately
Dimmer electronic; color blend stepless; color change adjustable; colors preset
Strobe effect
16 integrated show programs
The device is cooled by passive convection cooling
Control via stand-alone; master/slave function; sound to light via microphone; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Fixtures available for Light Captain
Flicker-free
With a beam angle of 120°
With mounting bracket
4 digit 7-segment LED display
Mains input and output for power linking up to 8 units
For application areas such as: Clubs/dancing school; decoration; mobile djs / entertainer; party room; restaurants, bars and hotels; advertisement/Shop window
Silent operation
Application possibility: Suspended; wall mounting
