Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	110 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Power output:	P-Con (gray), mounting version
Fuse:	T 2 A fuse replaceable
Lamp type:	LED lamp
LED type:	4 x 30 W COB (chip-on-board) 4in1 QCL RGBW (homogenous color mix)
Flash rate:	0 - 20 Hz
DMX channels:	3; 4; 5; 6; 8; 16; 20
DMX input:	3-pin XLR (M) mounting version
DMX output:	3-pin XLR (F) mounting version
Cooling:	2 x low-noise cooling fan
Control:	Stand-alone; IR remote control; DMX; master/slave function; sound to light via microphone; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Fixtures available for:	Light Captain; EASY SHOW 2; EASY SHOW 1; EASY SHOW 3; Light´J; Colorchief
Projection:	Flicker-free
Beam angle:	45°
Beam angle (1/2 peak):	45°
Beam angle (1/10 peak):	74°
Housing color:	Black
Attachment system:	Mounting bracket
Display type:	LCD display
Material:	Aluminum casting; metal
Dimensions:	Length: 49.0 cm Depth: 16.3 cm Height: 20.6 cm
Weight:	5.75 kg
Noise classification:	Class 1 (very slight noise, suitable for noise-sensitive environments)
Photobiological safety:	Risk Group 0
Mounting bracket
Diameter mounting holes:	3 x Ø11mm; 1 x Ø10mm; 2 x Ø8mm; 2 x Ø6mm
Material:	Metal, 3 mm
Power cord
Cable construction:	3 x 1.0 mm² H05RN-F
Cable length:	Approx. 1.2 m
Remote control
Battery:	1 x button cell 3.0 V CR2025 lithium manganese built-in
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397688634	6,35 kg	54cm x 20cm x 31cm
2	4026397688641	14,00 kg	55,7cm x 39,7cm x 32cm

Spare parts

cover (Plastic) LED PMB-4/8 QCL RGB black

LED COB 30W RGBW LED PMB-8 COB QCL 30W ()

Fan 12V/0,15A 60x60x15 (DC 12S6015)

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Dimensional drawing

Name	Version	Language
51930287-Dimensions-162489-1.0000-51930287dimensionspdf-de.pdf (107 KB)	1.0000	de

Support

Name	Version	Language
51930287-Support-136624-Fixture-fuer-Colorchief-V2X-de.zip (240 B)	0.0000	de

All images

Name	Version	Language
51930287-Images-.zip

Publications

Move Magazine #1/2021 E

On page: 57

Size: 43 MB

Move Magazine #2/2024 E

On page: 84

Size: 14 MB

Video link

https://www.youtube-nocookie.com/embed/yXBypzinM_A

EUROLITE LED PMB-4 COB QCL 30W Bar

Name: EUROLITE LED PMB-4 COB QCL 30W Bar
Uploaded: 2022-01-01
Description: LED light effect bar with RGBW color mixing, incl. IR remote control

LED light effect bar with RGBW color mixing, incl. IR remote control-MainBild

LED light effect bar with RGBW color mixing, incl. IR remote control-Bild-1

EUROLITE LED PMB-4 COB QCL 30W Bar

Stock for approx. 12 wk(s)

285,00 €

239,50 €

-16% valid until 30.04.2026

Find a dealer

Stock for approx. 12 wk(s)

List price excl. 19% VAT
Prices in retail stores may vary.

No. 51930287

45°

LED light effect bar with RGBW color mixing, incl. IR remote control

4 LEDs 30 W COB (chip-on-board) 4in1 QCL RGBW (homogenous color mix)
Color blend stepless; color change adjustable; color fade adjustable; Dimmer electronic
Strobe effect
Integrated show programs
Direct color selection for 27 preset colors
The device is cooled by low-noise cooling fan
Control via stand-alone; IR remote control; DMX; master/slave function; sound to light via microphone; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Fixtures available for Light Captain; EASY SHOW 2; EASY SHOW 1; EASY SHOW 3; Light´J; Colorchief
Flicker-free
With a beam angle of 45°
With mounting bracket
LCD display
Mains input and output for power linking up to 8 units
For application areas such as: Stage; clubs/dancing school; wedding/gala/events; Trade fair and shop fitting; restaurants, bars and hotels; theater; rental; video and photography; advertisement/Shop window
Very quiet working noise
Application possibility: Standing; suspended; on stand
