Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	265.00 W
DMX channels:	6/8
DMX connection:	3-pin XLR
Flash-rate:	13 Hz
Color-wheel:	7 dichroic filters and open
Rotating gobo-wheel:	7 gobos and open
Maximum PAN-movement:	360°
Maximum TILT-movement:	250°
Length of base:	330 mm
Width of yoke:	335 mm
Height (head horizontal):	360 mm
Weight:	12 kg
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397130539	14,40 kg	37cm x 38cm x 43cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

DMX protocol

Name	Version	Language
51786410-DMX-4314-de_en_es_fr.pdf (65 KB)	0.0000	de_en_es_fr

Support

Name	Version	Language
51786410-Support-14179-de_en_es_fr.dsp (7 KB)	0.0000	de_en_es_fr
51786410-Support-14189-de_en_es_fr.dsp (6 KB)	0.0000	de_en_es_fr

Press report

Name	Version	Language

Video file

Name	Version	Language
51786410-Video-46639-de_en_es_fr.flv (7 MB)	0.0000	de_en_es_fr

All images

Name	Version	Language
51786410-Images-.zip

EUROLITE TMH-155 Moving-Head

The article is no longer in our assortment.

No. 51786410

Moving head with rotating gobos

Versatile Moving-Head with a wide range of illumination and decoration possibilities
7 brilliant, dichroic colors plus white
7 rotating metal gobos plus open
All gobos can be interchanged
Manual focus
Strobe effect with 1-13 flashes per second
Exact positioning within 360° Pan and 250° Tilt
4-digit LED display for starting address
For bright 150 W discharge lamp
Suitable EUROLITE controllers: DMX Operator

Technical specifications

Spare parts

User manual

Downloads

Manufacturer information
