Technical specifications
Power supply:
230 V AC, 50 Hz
Power consumption:
320.00 W
Dimensions:
Width: 27 cm
Depth: 55.5 cm
Height: 28.5 cm
DMX channels:
5
DMX connection:
3-pin XLR
Sound-control:
via built-in microphone
Flash-rate:
1-7 Hz
Number of colors:
14 dichroic + white
Number of gobos:
14 gobos and open
PAN-movement:
within 180°
TILT-movement:
within 90°
Dimensions (L x W x H):
555 x 270 x 285 mm
Weight:
8 kg
Legal specifications
Special product:
Not designed for household room illumination
Intended use:
Show effect lighting
Packaging units
PU
EAN
Weight
Dimensions
1
4026397120868
9,75 kg
58,5cm x 30,5cm x 32,5cm
Spare parts
Mirror (oval) 110x70mm
cpu TS-150 0130-A (U2)
FUTURELIGHT Ignitor (ZG3,0D) MSD-200
FUTURELIGHT Ignitor (NI 400LE 4K) CDM 150W BAG
Lampsocket G-12 for TC-150
Downloads
Spezifications
Name
Version
Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral
DMX protocol
Name
Version
Language
51786020-DMX-4318-de_en_es_fr.pdf (62 KB)
0.0000
de_en_es_fr
51786020-DMX-4352-de_en_es_fr.doc (36 KB)
0.0000
de_en_es_fr
Support
Name
Version
Language
51786020-Support-4226-de_en_es_fr.dsp (8 KB)
0.0000
de_en_es_fr
51786020-Support-14190-de_en_es_fr.dsp (8 KB)
0.0000
de_en_es_fr
51786020-Support-57780-1.0000-Geraetefile-fuer-Eurolite-PC-Software-de.lpp (10 KB)
1.0000
de
Illustration
Name
Version
Language
1.0000
de
51786020-Illustration-14172-Poster-de.pdf (416 KB)
0.0000
de
Service document
Name
Version
Language
51786020-Service-2183-1.0000-de_en_es_fr.pdf (392 KB)
1.0000
de_en_es_fr
51786020-Service-2184-1.1000-de_en_es_fr.pdf (125 KB)
1.1000
de_en_es_fr
Video file
Name
Version
Language
51786020-Video-40286-de_en_es_fr.flv (5 MB)
0.0000
de_en_es_fr
All images
Name
Version
Language
51786020-Images-.zip
EUROLITE TS-150 Scan
Double tap or pinch to zoom
Hover to zoom
Bildergalerie öffnen
Detail images (11 overall)
EUROLITE TS-150 Scan
The article is no longer in our assortment.
No. 51786020
Bright scanner
DMX-controlled operation or stand-alone operation with Master/Slave function
For bright 150 W discharge lamp
Color-wheel with 12 dichroic color filters, 2 bi-color filters and white
Gobo-wheel with 14 gobos and open
Manual focus
Strobe effect with adjustable speed (1-7 flashes/sec.)
DMX control via every standard DMX controller
5 DMX control channels required
Sound-controlled via built-in microphone
5 high-quality stepping-motors
Suitable EUROLITE controllers: DMX Operator
