Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	1300 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Mains input via PowerCON (blue), mounting version power supply cord with safety plug (provided)
Warm-up time:	Approx. 10 min
Output distance:	Approx. 6 m
Tank capacity:	6.0 l water-based fluid removable tank
Fluid consumption:	Approx. 100 ml/min
DMX input:	1 x 5-pin XLR (M) mounting version
DMX output:	1 x 5-pin XLR (F) mounting version
Control:	Wired remote control (optional); DMX; stand-alone; wireless remote control
Carrier frequency:	433.92
Housing color:	Red
Heater:	1300 W
Display type:	Monochrome LCD display
Color:	Red
Dimensions:	Width: 27.8 cm Depth: 58 cm Height: 26.5 cm
Weight:	14.50 kg
Noise classification:	Class 3 (clearly perceptible sounds)
Remote control
Battery:	1 x 12 V LR27 alkaline manganese built-in

Packaging units

PU	EAN	Weight	Dimensions
1	4719850651923	16,00 kg	68cm x 37cm x 35cm
1	4026397546323	16,05 kg	67cm x 37cm x 35cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

All images

Name	Version	Language
51702602-Images-.zip

Video link

ANTARI FT-100 Fogger

Name: ANTARI FT-100 Fogger
Uploaded: 2022-01-01
Description: 1300 W fog machine for fire departments and rescue services

Stock for approx. 8 wk(s)

779,00 €

Find a dealer

Stock for approx. 8 wk(s)

List price excl. 19% VAT
Prices in retail stores may vary.

No. 51702602

1300 W fog machine for fire departments and rescue services

Specifically designed for fire training purposes
Two large rotary knobs and blue LCD screen allow users to set and control fog output volume and timer settings with ease, even when wearing heavy-duty gloves
Generating high volume thick fog in short time to simulate dense fog at fires
Rugged metal housing
Output distance: Approx. 6 m
Big tank capacity
With level indication
Operates on water-based fluid
Removable tank
Control via wired remote control (optional); DMX; stand-alone; wireless remote control
Monochrome LCD display
For application areas such as: Fire Departments
