Technical specifications

IP classification:	IP56
Power:	Program: 600W Rated: 300W RMS
Frequency range:	55 - 18000 Hz
Sensitivity:	98 dB (1W/1m)
Max. SPL:	123 dB
Dispersion angle:	80° x 80°
Impedance:	8 ohms; public address systems 100V
Attachment system:	Mounting bracket
Power tapping:	50W; 100W; 200W RMS via selector switch switchable
Connections:	Input: speaker via screw terminal
Crossover frequency:	2000 Hz
Speaker:	1 x woofer 12" Basket material: aluminum Conematerial: cardboard/paper Voice coil lows 3" 1 x compression tweeter highs 1" Voice coil compression tweeter highs 1.7"
Type of speaker:	On ceiling/on wall speaker
Material:	Plastic
Color:	Grey
Dimensions:	Width: 40 cm Depth: 38 cm Height: 41 cm
Weight:	19.65 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397703214	21,50 kg	47cm x 45cm x 46,5cm
1	4026397723045	21,75 kg	47cm x 44,5cm x 46,5cm

Spare parts

woofer 12" 8Ohm 300W ODX-212TM

Voicecoil ODX-212T

Bracket ODX-212T (1-part) white

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

All images

Name	Version	Language
11036965-Images-.zip

Publications

Move Magazine #1/2022 E

On page: 63

Size: 45 MB

OMNITRONIC ODX-212TM Installation Speaker 100V dark grey

Name: OMNITRONIC ODX-212TM Installation Speaker 100V dark grey
Brand: OMNITRONIC
SKU: 11036965
Price: 489.00 EUR
Availability: InStock

Weather-proof 12" wall speaker (IP56) with mount, 300 W RMS-MainBild

Weather-proof 12" wall speaker (IP56) with mount, 300 W RMS-Bild-1

OMNITRONIC ODX-212TM Installation Speaker 100V dark grey

Stock for approx. 12 wk(s)

489,00 €

Find a dealer

Stock for approx. 12 wk(s)

List price excl. 19% VAT
Prices in retail stores may vary.

No. 11036965

Weather-proof 12" wall speaker (IP56) with mount, 300 W RMS

Well-balanced sound
2-way coaxial system with 30 cm woofer (12") and 4 cm tweeter (1.7")
Power selector switch with 8 ohms operating position
Screw terminals for parallel connection
With mounting bracket
Grey aluminum grille with acoustic foam
Suitable for outdoor use IP56
For application areas such as: Installation; sports centres/gyms; multi-purpose hall
